Product Description
Karcher KM 150/500 R Bp Rider Floor Sweeper with 2 Side Brooms and Overhead Guard
The Karcher KM 150/500 R Bp is a heavy-duty battery powered rider floor sweeper designed for large-scale sweeping in demanding commercial and industrial environments. This configuration includes 2 side brooms and an overhead guard, making it a strong fit for schools, universities, municipal facilities, airports, warehouses, and industrial buildings that need maximum sweeping width with zero-emission operation and added operator protection.
This rider sweeper (ride-on sweeper) is built for the toughest jobs with a robust steel chassis, fully hydraulic traction drive and sweeping system, and a large hopper for high-volume debris collection. The KM 150/500 platform is designed for demanding conditions where sweeping productivity, debris capacity, and long operating cycles matter more than compact footprint, while still supporting quieter and emission-free battery sweeping.
With up to 71 inches of sweeping width using two side brooms, a massive 132 gallon steel hopper, and practical performance for heavy-duty dust and debris collection, the KM 150/500 R Bp is built for operators who need a durable industrial sweeper that can handle large indoor or outdoor areas efficiently without engine exhaust.
Recommended Applications
- Municipal and government facilities
- Schools, universities, and educational campuses
- Airports and transportation terminals
- Parking garages and large parking structures
- Warehouses and distribution centers
- Manufacturing facilities and industrial plants
- Convention centers and event venues
- Large commercial campuses and exterior hard surface areas
- Facilities with heavy dust, sand, or coarse debris
Key Features
- Heavy-duty battery rider sweeper built for large-scale industrial and commercial sweeping
- Two side brooms increase sweeping width for maximum area coverage
- Fully hydraulic traction drive and sweeping system for durable long-term performance
- Robust steel chassis and steel hopper support demanding applications
- Large 132 gallon debris hopper helps reduce dumping frequency on large jobs
- Flat pleat filter system supports effective dust control
- Dual scraper filter cleaning helps maintain sweeping performance in dusty conditions
- Main cylindrical broom and filter can be replaced without tools
- Clearly arranged operator controls improve usability
- Overhead guard adds operator protection for more demanding environments
- Zero-emission operation supports indoor and noise-sensitive sweeping applications
- Designed for demanding sweeping conditions from fine dust to heavier industrial debris
Why Choose a Battery Rider Sweeper?
This configuration uses battery power instead of LPG. Battery rider sweepers are often chosen for indoor or noise-sensitive areas where zero emissions, lower noise, and reduced engine maintenance are priorities.
- Zero-emission operation for indoor use
- Lower noise than LPG sweepers
- Strong fit for schools, hospitals, government, and public buildings
- No fuel handling required
How to Choose Between the KM 130/300 and KM 150/500 Versions
Karcher offers both the KM 130/300 and KM 150/500 platforms in multiple power and configuration options. This can be confusing for buyers, so here is the simple breakdown.
- KM 130/300 - Smaller hopper, narrower main broom, lighter machine, and a better fit for facilities that need industrial sweeping power in a more compact platform
- KM 150/500 - Larger hopper, wider sweeping path, heavier-duty design, and better for the largest debris loads and highest productivity requirements
- Bp versions - Battery powered, lower noise, zero emissions, stronger fit for indoor or noise-sensitive use
- Lpg versions - Engine powered, longer runtime, faster travel, stronger fit for outdoor or ventilated industrial applications
- 1 Side Broom versions - Narrower sweeping width and lower initial cost
- 2 Side Broom versions - Wider sweeping width for maximum productivity
- Overhead Guard versions - Added operator protection
- Front/Rear Lights or Working Lights versions - Improved visibility for darker work areas
Best For
- Municipal and government facilities with large sweeping areas
- Schools, universities, and public campuses that need zero-emission sweeping
- Airports, terminals, and public works operations
- Large industrial and manufacturing facilities requiring battery power
- Facilities that need a large-capacity rider sweeper with maximum sweeping width
- Operators who want overhead guard protection and dual side brooms included
Not Ideal For
- Facilities that prefer engine-powered machines for the longest uninterrupted runtime
- Outdoor-only applications where LPG may be preferred for extended shifts
- Small facilities where a compact rider or walk-behind sweeper would be more appropriate
- Applications where a narrower cleaning path is more practical than a wide 2SB layout
Specifications
- Manufacturer SKU: 9.841-342.0
- Machine Type: Rider Floor Sweeper
- Model: KM 150/500 R Bp
- Power Source: Battery / DC motor
- Power: 48V / 10 kW
- Main Broom Width: 47 in
- Working Width (1 Side Broom): 59 in
- Working Width (2 Side Broom): 71 in
- Waste Container Capacity: 132 gal
- Maximum Area Performance (2 Side Brooms): 193,752 sq ft/hr
- Working Speed: 5 mph
- Climbing Capacity: 12%
- Filter Area: 75 sq ft
- Weight: 5,650 lb
- Dimensions: 96 x 61 x 65 in
- Overhead Guard: Included
- Side Brooms: 2
- Charger: Standard Charger
Free Equipment Demonstration - No Obligation
Interested in seeing how the Karcher KM 150/500 R Bp rider floor sweeper performs in a real facility? Monster Janitorial can help arrange a demonstration so you can evaluate sweeping performance before purchasing.
- See how rider sweepers clean large facilities efficiently
- Compare rider sweepers vs walk-behind sweepers
- Review machine productivity, filtration, and debris handling
- Evaluate equipment performance for your facility type
- No obligation to purchase
To request a demonstration, email sales@monsterjanitorial.com or call 956-772-4842.
Included with the Machine
- Karcher KM 150/500 R Bp rider floor sweeper
- 2 side brooms
- Overhead guard
- Warning beacon
- Rear back-up alarm
- Steel hopper
- 6.987-083.0 - Side Brush, Regular
- 6.987-085.0 - Main Cylindrical Brush, Regular, 47 in
- 4.515-329.0 - Front Wheel, Solid Rubber, Puncture-Proof (Set of 2)
- 6.988-159.0 - Flat Pleat Filter, Green (2 Required)
- 8.636-896.0 - Battery, 24V, 721 Ah Steel Case (2 Required)
- 8.637-291.0 - Battery Charger, 48V, Standard
Optional Accessories and Replacement Wear Parts
- 6.905-773.0 - Side Brush, Hard
- 6.905-620.0 - Side Brush, Soft
- 6.905-619.0 - Side Brush, Hard Steel Bristles
- 8.636-953.0 - Front/Rear Light Kit
- 8.640-256.0 - Comfort Seat
- 8.640-208.0 - Seat Belt
- 6.987-436.0 - Main Cylindrical Brush, Hard, 47 in
- 6.987-437.0 - Main Cylindrical Brush, Soft, Natural, 47 in
- 8.636-989.0 - Left Side Broom Kit
- 6.987-177.0 - Flat Pleat Filter, White (2 Required)
- 8.638-992.0 - Dust Control Cover for Side Brush
- 8.638-990.0 - Overhead Guard
- 8.638-991.0 - Overhead Guard with Windscreen and Wiper
- 8.638-975.0 - Water Spray Dust Control System
Replacement Parts and Manuals
Manuals and Documents
Power and Configuration Options
The KM 150/500 family is available in several configurations, which can be confusing for buyers comparing part numbers. This machine is the battery version with 2 side brooms and overhead guard.
- KM 150/500 R Bp - Battery powered version for zero-emission, lower-noise sweeping
- 1 Side Broom versions - Narrower sweeping width and lower initial cost
- 2 Side Broom versions - Wider sweeping width for maximum productivity
- Overhead Guard versions - Added operator protection
- Standard Charger versions - Traditional charging setup
- High-Efficiency Charger versions - Improved charger performance, commonly preferred in some regions
- Lpg versions - Better for longest runtime and outdoor or ventilated industrial use
Battery and Charger Options
The KM 150/500 R Bp uses a 48V battery system with steel case batteries. This configuration includes the standard charger, which is the traditional charging setup for this machine family.
- Battery Version (This Machine) - Zero-emission sweeping for indoor or noise-sensitive applications
- 2 Steel Case Batteries Required - 8.636-896.0
- Standard Charger Included - 8.637-291.0
- High-Efficiency Charger Alternative - 8.637-293.0
Compared with LPG versions, the battery models are better for schools, hospitals, government buildings, and other environments where zero emissions and lower noise matter most.
Other KM 150/500 Configurations
- 9.841-343.0 - KM 150/500 R Bp 2SB with overhead guard and front/rear lights
- 9.841-348.0 - KM 150/500 R Bp 2SB with overhead guard and high-efficiency charger
- 9.841-345.0 - KM 150/500 R Bp with overhead guard
- 9.841-406.0 - KM 150/500 R Lpg 2SB with overhead guard
Explore Rider Floor Sweeper Configurations
The KM 150/500 series is available in multiple power and configuration options depending on facility needs. Browse similar machines below to compare sweeping width, power type, and debris capacity.
- Shop All Ride-On Floor Sweepers - Compare all commercial rider sweepers for large facilities.
- Battery Ride-On Sweepers - Zero-emission sweepers ideal for schools, hospitals, and indoor facilities.
- LPG / Propane Ride-On Sweepers - Long runtime sweepers designed for large outdoor or ventilated facilities.
- Industrial Ride-On Sweepers - Large-capacity machines for warehouses, airports, and public works.
Explore More Karcher Cleaning Equipment
Helpful Resources
- How to Choose a Floor Sweeper for Schools and Universities
- Best Floor Sweepers for Hospitals and Healthcare Facilities
- Commercial Floor Sweepers for Government Buildings
Manufacturer Warranty
The Karcher KM 150/500 R Bp rider floor sweeper is backed by the Karcher North America commercial equipment warranty program for professional sweeping equipment.
- 10 Years - Roto-molded polyethylene housing
- 3 Years - Parts
- 3 Years - Labor
- 6 Months - Travel coverage for on-site service
This warranty applies to defects in materials and workmanship under normal commercial use when serviced by an authorized Karcher service provider.
View the Full Karcher North America Machine Warranty (PDF)
Frequently Asked Questions
What is the advantage of the 2 side broom configuration?
The 2 side broom version increases sweeping width to help cover more ground per pass, making it a stronger choice for large open areas where productivity matters most.
Why choose the battery version instead of the LPG version?
The battery version is typically chosen for indoor or noise-sensitive applications where zero emissions and lower operating noise are important.
What does this specific 9.841-342.0 configuration include?
This machine includes battery power, 2 side brooms, overhead guard, and a standard charger.
Can the main broom and filter be replaced easily?
Yes. Karcher designed the KM 150/500 platform so the main cylindrical broom and filter can be replaced without tools, helping reduce maintenance time.
Is this machine a good fit for indoor school or government facilities?
Yes. Compared with LPG versions, this battery configuration is often the better fit for schools, government facilities, and other environments where zero emissions and lower noise are important.
